Detailed Info
Technical Parameters
NO. | Model | HF4040/6060 |
1 | X,Y,Z Working Area | 400x400x120mm(Z option 100mm or more) |
2 | Table Size | 580X720mm |
3 | XYZ Positional Accuracy | ±0.03/300mm |
4 | XYZ Repeatiblity Accuracy | ±0.05mm |
5 | Lathe Structure | Cast Aluminum lathe bed |
6 | X, Y, ZStructure | Taiwan Hiwin Round Guide Rail |
7 | Transmission | Original TBI Ball Screw |
8 | Table Surface | T slot with PVC + aluminum extrusions |
9 | Gantry Structure | Cast Aluminum Gantry |
10 | Max. Speed | 0-6000mm/min |
11 | Max. Working Speed | 0-3000mm/min |
12 | Spindle Power Motor | 2.2kw |
13 | Spindle Speed | 0-24000RPM |
14 | Drive Mode | Leadshine Stepper Motor |
15 | Working Voltage | AC220V/380V, 50/60Hz |
16 | Command | G code, *uoo, *mmg, *plt |
17 | Operating System | NC Studio System or DSP System or Marh3 CNC |
18 | Interface | USB/Internet Line |
19 | Collet and Tools | ER11, φ3.175, φ6 |
20 | X,Y Working Delicacy | <0.01mm |
What applications our mini cnc router machine can be applied to?
Mini cnc router has a very wide range of application.
1.It can applied to the advertising field.Sigh marking,Acrylic engraving and cutting,Crystal word marking,and other advertising material marking.
2.Wood field:Wave plate,Plywood,MDF and other wood materials.
3.3D relief.It can process the 3D relief on wood,stone,soft metal and other.
4. Die industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold
Main applications
1) Wood furniture industry:Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2) Other wood products industry: speakers, game consoles cabinets, computer tables, sewing machine table, musical instruments, etc.
3) Decoration industry: folding screen, wave plates, large wall, advertising boards, signs and logo’s processing.
4) Board processing industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, and other non-metallic mold.
2) Other wood products industry: speakers, game consoles cabinets, computer tables, sewing machine table, musical instruments, etc.
3) Decoration industry: folding screen, wave plates, large wall, advertising boards, signs and logo’s processing.
4) Board processing industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, and other non-metallic mold.
